Introducing The Series H4100 Acoustic Accordion Partition, A State-of-the-art Solution For Interiors Requiring Both Sight And Sound Barriers. With An Impressive STC Rating Of 41, This Partition Is Specifically Designed To Provide Superior Sound Insulation In Spaces That Demand Frequent Flexibility In Room Division.
Constructed With Two Continuous Laminated Vinyl Covers And Steel Pantographs Supported By Aluminum-covered Steel Channel Posts, The H4100 Series Stands Out For Its Enhanced Acoustical Performance. This Is Further Augmented By Steel Strips Laminated Within Each Fold, Ensuring The Partition Not Only Operates Easily But Also Remains Durable Over Time.
Our Custom-designed Accordion Partitions Cater To The Specific Needs Of Any Space, Featuring Clean, Crisp Lines And Multi-ply Soft Vinyl Sweepstrip Sound Seals At Both The Top And Bottom. This Laminated Construction Guarantees That The Covers Will Maintain Their Integrity Without Sagging Or Bagging.
The Partitions Boast Full-height Dual-magnetic Closure Strips In The Jamb, Allowing For Easy Closure And Enhanced Sound Sealing. The Laminated Cover Construction Adds Both Strength And Stability, Ensuring Years Of Smooth, Easy Folding Action And Effortless Door Maneuverability.
A Selection Of Heavy-duty Aluminum Track Systems Is Available, Accommodating Various Ceiling Conditions And Installation Requirements. The Partitions Come With Nylon-tired Steel Ball-bearing Wheels, Four-wheeled Carriers On Each Lead Post And Intermediate Carriers For Smooth Movement.
Technical Specifications Include Internal Framing Of 14 Gauge Steel, Clear Anodized Aluminum Trimmed Lead Posts With Mechanical Latching, And Aluminum Handles With Steel Pull Handles For Ease Of Use. The Latch Mechanism, Which Includes A Thumb-turn On One Or Both Sides, Offers Additional Security With A Range Of Keylock Options.
These Partitions Are Designed For Maximum Flexibility, With No Maximum Width Constraints And Heights Up To 12 Feet. The Stack Width Is Efficiently Designed To Be 5-1/2 Inches When Extended And 7-1/2 Inches When Closed, Ensuring The Partition Is Both Space-efficient And Easy To Store. The Partition Hanging Weight For The H4100 Model Is 4.3lb Per Sq Ft.
Certified With An STC Rating Of 41 Following The ASTM E90 Test Procedures, The Series H4100 Continuous Vinyl Acoustical Partition Is The Ideal Choice For Environments That Require Effective Sound Control Along With The Flexibility To Adapt To Changing Space Requirements.
